Manual Transaxle Gear Shift Fork & Shaft fit your 1993 Chevrolet Prizm

Currently shopping for

1993 Chevrolet Prizm

Change Vehicle

Vehicle Options

GEO Prizm 4 Door

Vehicle Options

GEO Prizm 4 Door

Categories Close X

Currently selected

Transmission - Manual

Other Categories

Body Moldings, Sheet Metal, Rear Compartment Hardware, Roof Hardware

Body Mounting, Air Conditioning, Audio/Entertainment

Body Wiring, Roof Trim

Brakes

Brakes, Rear Axle, Propeller Shaft, Wheels, Tires

Cooling System, Grille, Oil System

Engine

Frames, Springs, Shocks, Bumpers, Fascias

Front End Sheet Metal, Heater

Front Suspension, Steering

Fuel System, Exhaust, Emission System

Interior Trim, Front Seat Trim, Seat Belts

Rear Glass, Seat Parts, Adjuster

Rear Seat Trim, Carpet

Starter, Generator, Ignition, Electrical, Lamps

Transmission - Automatic

Windshield, Wiper, Mirrors, Instrument Panel, Console, Doors

How to use OE catalog

Sort by:

Recommended

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

94853938
SPRING, Transmission Synchronizer, SPRING,3RD & 4TH GEAR SYN(24.6MM OUTSIDE DIAMETER)(SEAT)(49.9MM LONG)
$4.14 $0.68
1
Add To Cart

94855593
ARM, Transmission Internal Shift, ARM,3RD & 4TH SHIFT FORK(WHEN USING TO REPLACE 1985-92 OR 1993 W/PRODUCTION DATE PRIOR TO 06/93 USE 1-94855596 SEAT)
$28.67 $4.67
1
Add To Cart

94840621
GASKET, Transmission Control Lever, GASKET,SHIFT CONTROL SHAFT COVER

94840627
GASKET, Transmission Interlock, GASKET,SHIFT INTERLOCK PLATE BOLT(2.5MM THICK)(12.3MM INSIDE DIAMETER, 21MM O.D.)

94840627
GASKET, Transmission Internal Shift, GASKET,SHIFT INTERLOCK PLATE BOLT(2.5MM THICK)(12.3MM INSIDE DIAMETER, 21MM O.D.)

94840756
SHOE, Transmission Internal Shift, SHOE,REV SHIFT FORK

94840764
SHAFT, Transmission Rail End, SHAFT,SHIFT CONTROL

94840765
PLATE, Transmission Internal Shift, PLATE,SHIFT INTERLOCK

94840765
PLATE, Transmission Interlock, PLATE,SHIFT INTERLOCK

SEAT, Transmission Internal Shift
94840766
SEAT, 1ST & 2ND SELECTOR STOP SPRING(34MM OUTSIDE DIAMETER)(USED THROUGH PRODUCTION DATE 05/93)(2ND DESIGN 94855595)
Fitting Vehicle Options: S(MM5)(1ST DES)
94855595
SEAT, 1ST & 2ND SELECTOR STOP SPRING(18MM INSIDE DIAMETER, 34MM OUTSIDE DIAMETER)(14MM HIGH)(USED FROM PRODUCTION DATE 06/93)(1ST DESIGN 94840766)
- Fitting Vehicle Options: S(MM5)(2ND DES)

SEAT, Transmission Synchronizer
94840767
SEAT, 3RD & 4TH GEAR SYN SPRING(32MM OUTSIDE DIAMETER)(USED THROUGH PRODUCTION DATE 05/93)(2ND DESIGN 94855596)
Fitting Vehicle Options: S(MM5)(1ST DES)
94855596
SEAT, 3RD & 4TH GEAR SYN SPRING(15MM INSIDE DIAMETER, 32MM OUTSIDE DIAMETER)(15.5MM HIGH)(USED FROM PRODUCTION DATE 06/93)(1ST DESIGN 94840767)
- Fitting Vehicle Options: S(MM5)(2ND DES)

94840768
COVER, Transmission Internal Shift Shaft, COVER,SHIFT CONTROL SHAFT

94840769
BOOT, Transmission Control Lever, BOOT,SHIFT CONTROL SHAFT

94840774
BALL, Transmission Shift Shaft Detent, BALL,5TH SHIFT SHAFT DETENT(9.53MM DIAMETER)

94840774
BALL, Transmission Internal Shift, BALL,3RD & 4TH SHIFT SHAFT DETENT(9.53MM DIAMETER)

94840774
BALL, Transmission Shift Shaft Detent, BALL,1ST & 2ND SHIFT SHAFT DETENT(9.53MM DIAMETER)

94840785
FORK, Transmission Internal Shift, FORK,REV SHIFT

94840786
BALL, Transmission Interlock, BALL,REV SHIFT FORK DETENT(6.35MM OUTSIDE DIAMETER)(STEEL)
- Require Quantity: 02
- Package Quantity: 1

94840787
PLUG, Transmission Interlock, PLUG,REV SHIFT SHAFT DETENT(INCLUDES: SPRING & LOCK BALL)

94840787
PLUG, Transmission Internal Shift, PLUG,REV SHIFT SHAFT DETENT(INCLUDES: SPRING & LOCK BALL)

BOLT, Transmission Internal Shift Shaft
94842250
BOLT, SHIFT CONTROL SHAFT COVER(M10X1.25X25)(CONTAINS WASHER-17.4MM O.D.)
Require Quantity: 02
Package Quantity: 1
94856602
BOLT, SHIFT CONTROL SHAFT COVER(M10X1.25X25)
- Require Quantity: 02
- Package Quantity: 1

94842645
PIN, Transmission Rail End, PIN,CONTROL SELECTOR ARM(M5.3X32)

94842645
PIN, Transmission Internal Shift, PIN,CONTROL SELECTOR ARM(M5.3X32)

94842646
PIN, Transmission Shift Shaft Detent, PIN,REV INHIBITOR(5.2MM OUTSIDE DIAMETER)(CAM RETAINER)(SLOTTED SPRING)(20MM LONG)

PIN, Transmission Interlock

94842647
PIN, 1ST & 2ND SHIFT FORK(ARM RETAINER)(5.2MM OUTSIDE DIAMETER)(SLOTTED SPRING)(25.5MM LONG)
94842647
PIN, 3RD & 4TH SHIFT FORK(ARM RETAINER)(5.2MM OUTSIDE DIAMETER)(SLOTTED SPRING)(25.5MM LONG)

PIN, Transmission Internal Shift

94842647
PIN, 3RD & 4TH SHIFT FORK(ARM RETAINER)(5.2MM OUTSIDE DIAMETER)(SLOTTED SPRING)(25.5MM LONG)
94842647
PIN, 1ST & 2ND SHIFT FORK(ARM RETAINER)(5.2MM OUTSIDE DIAMETER)(SLOTTED SPRING)(25.5MM LONG)

PLUG, Transmission Shift Shaft Detent
94842684
PLUG, REV INHIBITOR CAM PINION HOLE
Fitting Vehicle Options: (MM5)
94842684
PLUG, REV INHIBITOR CAM PINION HOLE(M10X1.25X7.5)(15MM ROUND HEAD, 6MM HEXAGON RECESS)
- Fitting Vehicle Options: S(MM5)

94842991
ARM, Transmission Internal Shift, ARM,1ST & 2ND SHIFT FORK

94843048
RING, Transmission Synchronizer, RING,3RD & 4TH GEAR SYN SPRING SEAT RETAINER(12MM INSIDE DIAMETER, 23MM OUTSIDE DIAMETER)(1.5MM THICK)

94843053
RING, Transmission Internal Shift, RING,REV SHIFT FORK SHOE RETAINER

94843108
BOLT, Transmission Interlock, BOLT,SHIFT INTERLOCK PLATE

94843108
BOLT, Transmission Internal Shift, BOLT,SHIFT INTERLOCK PLATE

94843437
RING, Transmission Internal Shift Shaft, RING,5TH SHIFT SHAFT RETAINER(12MM INSIDE DIAMETER, 17MM OUTSIDE DIAMETER)(1.5MM THICK)

94843437
RING, Transmission Internal Shift Fork, RING,REV SHIFT FORK RETAINER(12MM INSIDE DIAMETER, 17MM OUTSIDE DIAMETER)(1.5MM THICK)

94843437
RING, Transmission Internal Shift Shaft, RING,1ST & 2ND SHIFT SHAFT RETAINER(12MM INSIDE DIAMETER, 17MM OUTSIDE DIAMETER)(1.5MM THICK)

94843437
RING, Transmission Internal Shift Shaft, RING,3RD & 4TH SHIFT SHAFT RETAINER(12MM INSIDE DIAMETER, 17MM OUTSIDE DIAMETER)(1.5MM THICK)

94843438
RING, Transmission Internal Shift, RING,1ST & 2ND SELECTOR STOP SPRING SEAT RETAINER(15MM INSIDE DIAMETER, 21MM OUTSIDE DIAMETER)(1.5MM THICK)

94846156
BLOCK, Transmission Internal Shift, BLOCK,3RD & 4TH SHIFT

94846157
BOLT, Transmission Internal Shift, BOLT,3RD & 4TH SHIFT FORK(M6X0.75X21)

94846157
BOLT, Transmission Internal Shift, BOLT,3RD & 4TH SHIFT BLOCK(M6X0.75X21)

94846157
BOLT, Transmission Internal Shift, BOLT,5TH SHIFT FORK(M6X0.75X21)

94846157
BOLT, Transmission Internal Shift, BOLT,1ST & 2ND SHIFT FORK(M6X0.75X21)

94849494
CAM, Transmission Shift Shaft Detent, CAM,REV INHIBITOR(INCLUDES SHAFT)

94850206
FORK, Transmission Internal Shift, FORK,3RD & 4TH SHIFT

94851587
SPRING, Transmission Shift Shaft Detent, SPRING,1ST & 2ND SHIFT SHAFT DETENT

94851587
SPRING, Transmission Shift Shaft Detent, SPRING,3RD & 4TH SHIFT SHAFT DETENT

94851587
SPRING, Transmission Shift Shaft Detent, SPRING,5TH SHIFT SHAFT DETENT

94851593
FORK, Transmission Internal Shift, FORK,1ST & 2ND SHIFT

94851857
FORK, Transmission Internal Shift, FORK,5TH SHIFT

94851879
PLUG, Transmission Internal Shift, PLUG,5TH SHIFT SHAFT DETENT(INCLUDES SEAT)

94851879
PLUG, Transmission Interlock, PLUG,5TH SHIFT SHAFT DETENT(INCLUDES SEAT)

94851879
PLUG, Transmission Shift Shaft Detent, PLUG,1ST & 2ND SHIFT SHAFT DETENT(INCLUDES SEAT)

94851879
PLUG, Transmission Shift Shaft Detent, PLUG,3RD & 4TH SHIFT SHAFT DETENT(INCLUDES SEAT)

94854092
VENT, Transmission Case, VENT,MANUAL TRANSMISSION(10MM DIAMETER, 27MM LONG)

SPRING, Transmission Internal Shift
94854326
SPRING, 1ST & 2ND SELECTOR STOP(35MM LONG)(USED THROUGH PRODUCTION DATE 05/93)(2ND DESIGN 94855303)
Fitting Vehicle Options: S(MM5)(1ST DES)
94855303
SPRING, 1ST & 2ND SELECTOR STOP(76.4MM LONG)(1ST DESIGN 94854326)
- Fitting Vehicle Options: S(MM5)(2ND DES)

94854732
SEAL, Transmission Control Lever, SEAL,SHIFT CONTROL SHAFT COVER(18MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(8MM HIGH)

94855594
ARM, Transmission Control, ARM,CONTROL SELECTOR(USED FROM PRODUCTION DATE 06/93)(1ST DESIGN 94840763)

94855870
BRACKET, Transmission Internal Shift, BRACKET,REV SHIFT LEVER

94855870
BRACKET, Transmission Rail End, BRACKET,REV SHIFT LEVER

94855945
SHAFT, Transmission Internal Shift Shaft, SHAFT,1ST & 2ND SHIFT

94855946
SHAFT, Transmission Internal Shift Shaft, SHAFT,3RD & 4TH SHIFT(USE TOGETHER WITH 94855948 SPRING)

94855947
SHAFT, Transmission Internal Shift Shaft, SHAFT,5TH & REV SHIFT

Genuine GM Parts, the Right Choice

GMPartsGiant.com offers the wholesale prices for genuine 1993 Chevrolet Prizm parts. Parts like Manual Transaxle Gear Shift Fork & Shaft are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 1.6L, 4 Cyl 1.8L. Model Code: 4 DOOR.
