Automatic Transaxle Planetary, Reverse Piston & Counter Gear fit your 1999 Chevrolet Prizm

Currently shopping for

1999 Chevrolet Prizm

Change Vehicle

Vehicle Options

4 Cyl 1.8L MFI; Prizm 4 Door

Vehicle Options

4 Cyl 1.8L MFI; Prizm 4 Door

Categories Close X

Currently selected

Transmission - Automatic

Other Categories

Body Moldings, Sheet Metal, Rear Compartment Hardware, Roof Hardware

Body Mounting, Air Conditioning, Audio/Entertainment

Body Wiring, Roof Trim

Brakes

Brakes, Rear Axle, Propeller Shaft, Wheels, Tires

Cooling System, Grille, Oil System

Engine

Frames, Springs, Shocks, Bumpers, Fascias

Front End Sheet Metal, Heater

Front Suspension, Steering

Fuel System, Exhaust, Emission System

Interior Trim, Front Seat Trim, Seat Belts

Rear Glass, Seat Parts, Adjuster

Rear Seat Trim, Carpet

Starter, Generator, Ignition, Electrical, Lamps

Transmission - Manual

Windshield, Wiper, Mirrors, Instrument Panel, Console, Doors

How to use OE catalog

Sort by:

Recommended

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

BEARING, Transmission Sun Gear
94860010
BEARING, FRONT INTERNAL GEAR THRUST(25.8MM INSIDE DIAMETER, 42MM OUTSIDE DIAMETER)
Fitting Vehicle Options: S(MS7)
$22.98 $3.75
1
Add To Cart
94840931
BEARING, FRONT INTERNAL GEAR THRUST(22.2MM INSIDE DIAMETER, 36.1MM OUTSIDE DIAMETER)(NEEDLE)
- Fitting Vehicle Options: S(MB3)

94842760
RACE, Transmission Clutch, RACE,FRONT INTERNAL GEAR THRUST BEARING(19MM INSIDE DIAMETER, 35MM OUTSIDE DIAMETER)
$10.19 $1.66
1
Add To Cart

94843480
RING, Transmission Mainshaft, RING,REAR INTERNAL GEAR RETAINER(90MM OUTSIDE DIAMETER, 82MM INSIDE DIAMETER)(1.2MM THICK)(4.176)
$2.86 $0.46
1
Add To Cart

94843480
RING, Transmission Mainshaft, RING,REAR INTERNAL GEAR RETAINER(PART OF 23)(90MM OUTSIDE DIAMETER, 82MM INSIDE DIAMETER)(1.2MM THICK)(4.176)
$2.86 $0.46
1
Add To Cart

94843481
RING, Transmission Clutch, RING,LOW CLUTCH SPRAG RETAINER(121MM INSIDE DIAMETER, 130MM OUTSIDE DIAMETER)(1.0MM THICK)(4.167)
- Require Quantity: 02
- Package Quantity: 1
$3.65 $0.59
1
Add To Cart

94843482
RING, Transmission Clutch, RING,LOW CLUTCH SPRAG OUTER RACE RETAINER(140MM INSIDE DIAMETER, 149MM OUTSIDE DIAMETER)(1.6MM THICK)
- Require Quantity: 02
- Package Quantity: 1
$4.68 $0.77
1
Add To Cart

94843484
RING, Transmission Input, RING,FRONT INTERNAL GEAR FLANGE RETAINER(90MM INSIDE DIAMETER, 100MM OUTSIDE DIAMETER)(1.4MM THICK)
$2.95 $0.49
1
Add To Cart

FLANGE, Transmission Input
94853331
FLANGE, FRONT INTERNAL GEAR
Fitting Vehicle Options: S(MS7)
$94.67 $15.44
1
Add To Cart
94843790
FLANGE, FRONT INTERNAL GEAR
- Fitting Vehicle Options: S(MB3)

94851272
SPRAG, Transmission Clutch, SPRAG,LOW CLUTCH
$268.58 $36.18
1
Add To Cart

94851554
GEAR, Transmission Input, GEAR,FRONT INTERNAL
$149.02 $24.31
1
Add To Cart

94853334
SHAFT, Transmission Output/Counter Shaft or Carrier, SHAFT,OUTPUT(INCLUDES 24)(INCLUDES RING)
$227.98 $35.82
1
Add To Cart

94853888
RACE, Transmission Clutch, RACE,FRONT INTERNAL GEAR THRUST BEARING(26MM INSIDE DIAMETER, 39.5MM OUTSIDE DIAMETER)(4.176)
$13.09 $2.13
1
Add To Cart

94853892
BEARING, Transmission Output/Counter Shaft or Carrier, BEARING,OUTPUT SHAFT THRUST(26.7MM INSIDE DIAMETER, 37.5MM OUTSIDE DIAMETER)
$20.65 $3.36
1
Add To Cart

94853893
NUT, Transmission Output/Counter Shaft or Carrier, NUT,OUTPUT SHAFT(M22X1.5)(HEXAGON)(5.518)
$8.10 $1.32
1
Add To Cart

94853893
NUT, Pinion DIFFERENTIAL Shaft Lock, NUT,FRONT DIFFERENTIAL DRIVE PINION GEAR SHAFT(M22X1.5)(HEXAGON)
- Location: Driver Side
$8.10 $1.32
1
Add To Cart

94856941
CARRIER, Transmission Output/Counter Shaft or Carrier, CARRIER,FRONT
$221.49 $34.79
1
Add To Cart

94860011
BEARING, Transmission Sun Gear, BEARING,FRONT INTERNAL GEAR THRUST(REAR)(22.8MM INSIDE DIAMETER, 37.9MM OUTSIDE DIAMETER)(REAR)
$22.61 $3.69
1
Add To Cart

94840646
WASHER, Transmission Output/Counter Shaft or Carrier, WASHER,REAR CARRIER THRUST(61MM O.D.)
- Require Quantity: 02
- Package Quantity: 1

94840646
WASHER, Transmission Planet Carrier, WASHER,REAR CARRIER THRUST(61MM O.D.)
- Require Quantity: 02
- Package Quantity: 1

94840647
WASHER, Transmission Planet Carrier, WASHER,FRONT CARRIER THRUST(54MM INSIDE DIAMETER, 70.4MM OUTSIDE DIAMETER)(1.4MM THICK, 5.3MM DIAMETER PINS)

94840647
WASHER, Transmission Output/Counter Shaft or Carrier, WASHER,FRONT CARRIER THRUST(54MM INSIDE DIAMETER, 70.4MM OUTSIDE DIAMETER)(1.4MM THICK, 5.3MM DIAMETER PINS)

94840648
SEAL, Transmission Output/Counter Shaft or Carrier, SEAL,OUTPUT SHAFT(15MM INSIDE DIAMETER, 18MM OUTSIDE DIAMETER)(OIL)(1.9MM THICK)

94840926
GEAR, Transmission Rear Internal Gear, GEAR,REAR INTERNAL

94840927
FLANGE, Transmission Rear Internal Gear, FLANGE,REAR INTERNAL GEAR

94840933
BEARING, Transmission Output/Counter Shaft or Carrier, BEARING,REAR PLANET FLANGE THRUST(NEEDLE)(37.6MM O.D., 24MM INSIDE DIAMETER)

94840935
BEARING, Transmission Mainshaft, BEARING,INTERMEDIATE SHAFT FRONT(72MM O.D., 40MM INSIDE DIAMETER)(BALL)

94842758
RACE, Transmission Sun Gear, RACE,FRONT PLANET FLANGE REAR THRUST BEARING(38MM O.D., 22.1MM INSIDE DIAMETER)

94842759
RACE, Transmission Sun Gear, RACE,FRONT PLANET FLANGE FRONT THRUST BEARING(35.9MM OUTSIDE DIAMETER, 23.1MM INSIDE DIAMETER)

94842761
RACE, Transmission Clutch, RACE,FRONT PLANET GEAR REAR THRUST BEARING(45MM O.D., 29.2MM INSIDE DIAMETER)

94842763
RACE, Transmission Planet Carrier, RACE,REAR PLANET FLANGE THRUST BEARING(37.6MM OUTSIDE DIAMETER, 23.2MM INSIDE DIAMETER)

94843478
RING, Transmission Output/Counter Shaft or Carrier, RING,INTERMEDIATE SHAFT FRONT BEARING RETAINER

BEARING, Transmission Planet Carrier

94844769
BEARING, OUTPUT SHAFT(63MM OUTSIDE DIAMETER, 38MM INSIDE DIAMETER)(FRONT)(18MM HIGH)
94844978
BEARING, OUTPUT SHAFT(REAR)(56MM O.D., 37MM INSIDE DIAMETER)

94844978
BEARING, Transmission Planet Carrier, BEARING,OUTPUT SHAFT(REAR)

94844979
BEARING, Differential Pinion, BEARING,FRONT DIFFERENTIAL TRANSFER DRIVE GEAR THRUST(46MM INSIDE DIAMETER, 58MM OUTSIDE DIAMETER)(2.8MM HIGH)

94846777
GEAR KIT, Ring and Pinion, GEAR KIT,FRONT DIFFERENTIAL DRIVE PINION

94853330
RACE, Transmission Clutch, RACE,LOW CLUTCH SPRAG OUTER

94853341
GEAR KIT, Transmission Output/Counter Shaft or Carrier, GEAR KIT,OUTPUT & FRONT DIFFERENTIAL TRANSFER DRIVE

94853894
SPACER, Transmission Planet Carrier, SPACER,OUTPUT GEAR BEARING

94854405
BEARING, Transmission Output/Counter Shaft or Carrier, BEARING,OUTPUT SHAFT
- Require Quantity: 02
- Package Quantity: 1

94856942
CARRIER, Transmission Output/Counter Shaft or Carrier, CARRIER,REAR

94858521
BEARING, Transmission Mainshaft, BEARING,INTERMEDIATE SHAFT REAR

Genuine GM Parts, the Right Choice

GMPartsGiant.com offers the wholesale prices for genuine 1999 Chevrolet Prizm parts. Parts like Automatic Transaxle Planetary, Reverse Piston & Counter Gear are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 1.8L. Model Code: 4 DOOR.
