Fuel Injection System fit your 2004 Pontiac Vibe

Currently shopping for

2004 Pontiac Vibe

Change Vehicle

Categories Close X

Currently selected

Fuel System, Exhaust, Emission System

Other Categories

Body Moldings, Sheet Metal, Rear Compartment Hardware, Roof Hardware

Body Mounting, Air Conditioning, Audio/Entertainment

Body Wiring, Roof Trim

Brakes

Brakes, Rear Axle, Propeller Shaft, Wheels, Tires

Cooling System, Grille, Oil System

Engine

Frames, Springs, Shocks, Bumpers, Fascias

Front End Sheet Metal, Heater

Front Suspension, Steering

Interior Trim, Front Seat Trim, Seat Belts

Rear Glass, Seat Parts, Adjuster

Rear Seat Trim, Carpet

Starter, Generator, Ignition, Electrical, Lamps

Transfer Case

Transmission - Automatic

Transmission - Manual

Windshield, Wiper, Mirrors, Instrument Panel, Console, Doors

How to use OE catalog

Sort by:

Recommended

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

88969009
BODY, Fuel Injection Air Meter, BODY,THROTTLE(INCLUDES 13-17,22)(INCLUDES: IAC VALVE & T/POSITION SENSOR)
$1606.40 $830.95
1
Add To Cart

CLAMP, Fuel Line
88970234
CLAMP, FUEL INJECTION FUEL FEED PIPE(LOWER)
Fitting Vehicle Options: SM,SN(26)(LNK,LV6), SL(26)(LV6)
$3.27 $1.43
1
Add To Cart
94858610
CLAMP, FUEL INJECTION FUEL FEED PIPE(UPPER)
- Fitting Vehicle Options: SM,SL(LV6)

88974043
CONNECTOR, Fuel Injection, CONNECTOR,SEQUENTIAL MULTIPORT FUEL INJECTOR(2-WAY FEMALE)(W/O LEADS)(GRAY)(USE TOGETHER WITH 2-88973784 SERVICE REPAIR TERMINAL)
- Require Quantity: 04
- Package Quantity: 1
$22.83 $14.52
1
Add To Cart

INSULATOR, Fuel Injector
94845503
INSULATOR, FUEL INJECTOR(10MM INSIDE DIAMETER, 15MM 0D)(UPPER)(5.5MM HIGH)(*01)
Require Quantity: 04
Package Quantity: 1
$13.05
1
Add To Cart
88974209
INSULATOR, FUEL INJECTOR(9.2MM INSIDE DIAMETER, 16MM OUTSIDE DIAMETER)(LOWER)(5.5MM HIGH)(*01)
- Require Quantity: 04
- Package Quantity: 1

88974227
TERMINAL, Chassis Electrical, TERMINAL,WIRING
- Require Quantity: 03
- Package Quantity: 1
$10.72 $3.50
1
Add To Cart

94859012
SENSOR, Multi PORTION Fuel Injection Throttle Position, SENSOR,THROTTLE POSITION(PART OF 18)
$122.88 $65.56
1
Add To Cart

19205530
RAIL, Fuel Injection, RAIL,MULTIPORT FUEL INJECTION FUEL

88969011
BRACKET, Fuel Injection Air Meter, BRACKET,THROTTLE BODY

88969021
HOSE, Throttle Body Coolant Supply, HOSE,THROTTLE BODY HEATER OUTLET

88969026
GASKET, Multi PORTION Fuel Injection Throttle Body, GASKET,THROTTLE BODY(*01)

88969043
VALVE, Throttle Body/Carburetor, VALVE,IDLE AIR CONTROL(PART OF 18)

88969044
BOLT, Fuel Injection Air Meter, BOLT,THROTTLE BODY BRACKET(M8X1.25X49)(INCLUDES WASHER-17MM O.D.)
- Require Quantity: 02
- Package Quantity: 1

88969045
STUD, Multi PORTION Fuel Injection Throttle Body, STUD,THROTTLE BODY(M8X1.25X54)
- Require Quantity: 02
- Package Quantity: 1

88969046
NUT, Multi PORTION Fuel Injection Throttle Body, NUT,THROTTLE BODY(M8X1.25, 17.5MM O.D.)(8MM HIGH)
- Require Quantity: 02
- Package Quantity: 1

88969598
HOSE, Throttle Body Coolant Supply, HOSE,THROTTLE BODY HEATER INLET(CYL HEAD TO THROTTLE BODY)

88969599
HOSE, Throttle Body Coolant Supply, HOSE,THROTTLE BODY HEATER OUTLET(THROTTLE BODY TO BY-PASS PIPE)

88969622
STUD, Multi PORTION Fuel Injection Throttle Body, STUD,THROTTLE BODY(M8X1.25X56)
- Require Quantity: 02
- Package Quantity: 1

88969638
GASKET, Multi PORTION Fuel Injection Throttle Body, GASKET,THROTTLE BODY(*01)

88969640
RAIL, Fuel Injection, RAIL,MULTIPORT FUEL INJECTION FUEL(INCLUDES: DAMPENER & SEAL)

88969641
SPACER, Fuel Injection, SPACER,FUEL INJECTION FUEL RAIL(8.5MM INSIDE DIAMETER, 20MM OUTSIDE DIAMETER)(36MM LONG)
- Require Quantity: 02
- Package Quantity: 1

88969642
BOLT, Fuel Line, BOLT,FUEL INJECTION FUEL FEED PIPE CLA(BOLT,HEXAGON(M6X1.0X14), W/WASHER(16MM OUTSIDE DIAMETER), HEADER POINT)

88969643
BOLT, Fuel Injection, BOLT,FUEL INJECTION FUEL RAIL(BOLT,HEXAGON(M8X1.25X55), W/WASHER(18MM OUTSIDE DIAMETER), HEADER POINT)(8.900)
- Require Quantity: 02
- Package Quantity: 1

88969644
HOSE, Fuel Line, HOSE,FUEL INJECTION FUEL FEED(INCLUDES CONNECT)

88969645
CLAMP, Fuel Line, CLAMP,FUEL INJECTION FUEL FEED PIPE

88970218
BODY, Fuel Injection Air Meter, BODY,THROTTLE(INCLUDES 6-11)(INCLUDES: IAC VALVE & T/POSITION SENSOR)

88970220
SENSOR, Multi PORTION Fuel Injection Throttle Position, SENSOR,THROTTLE POSITION(PART OF 16)

88971581
PIPE, Fuel Line, PIPE,FUEL INJECTION FUEL FEED

88972792
BOLT, Throttle Body Throttle Position, BOLT,THROTTLE POSITION SENSOR(PART OF 18)
- Require Quantity: 02
- Package Quantity: 1

88972792
BOLT, Throttle Body Throttle Position, BOLT,THROTTLE POSITION SENSOR(PART OF 16)
- Require Quantity: 02
- Package Quantity: 1

88972794
GASKET, Throttle Body/Carburetor, GASKET,IDLE AIR CONTROL VALVE(PART OF 18)(*01)

88972794
GASKET, Throttle Body/Carburetor, GASKET,IDLE AIR CONTROL VALVE(PART OF 16)(*01)

88972795
BOLT, Multi PORTION Fuel Injection Throttle Body, BOLT,IDLE AIR CONTROL VALVE(PART OF 18)(M10X1.25, 11MM LONG)(14MM HEXAGON)
- Require Quantity: 02
- Package Quantity: 1

88972796
BOLT, Multi PORTION Fuel Injection Throttle Body, BOLT,THROTTLE BODY(BOLT, HEXAGON(M8X1.25X65), HEADER POINT)
- Require Quantity: 02
- Package Quantity: 1

HOSE, Throttle Body Coolant Supply
88972993
HOSE, THROTTLE BODY HEATER INLET
Fitting Vehicle Options: SM(26)(LV6)
94858997
HOSE, THROTTLE BODY HEATER INLET
- Fitting Vehicle Options: SL(26)(LV6)

88973239
VALVE, Throttle Body/Carburetor, VALVE,IDLE AIR CONTROL(PART OF 16)

88973784
TERMINAL, Chassis Electrical, TERMINAL,WIRING
- Require Quantity: 08
- Package Quantity: 1

88973784
TERMINAL, Chassis Electrical, TERMINAL,WIRING

88973784
TERMINAL, Chassis Electrical, TERMINAL,WIRING
- Require Quantity: 03
- Package Quantity: 1

88974047
CONNECTOR, Carburetor Accelerator Pump, CONNECTOR,VALVE-IDLE AIR CONTROL(3-WAY FEMALE)(W/O LEADS)(GRAY)(USE TOGETHER WITH 3-88973784 SERVICE REPAIR TERMINAL)

88974048
CONNECTOR, Multi PORTION Fuel Injection Throttle Position, CONNECTOR,SENSOR-THROTTLE POSITION(3-WAY FEMALE)(W/O LEADS)(BLACK)(USE TOGETHER WITH 3-88974227 SERVICE REPAIR TERMINAL)

88974567
INJECTOR, Fuel Injection, INJECTOR,MULTIPORT FUEL(INCLUDES 23,25(UPPER ONLY)
- Require Quantity: 04
- Package Quantity: 1

94842498
NUT, Multi PORTION Fuel Injection Throttle Body, NUT,THROTTLE BODY
- Require Quantity: 02
- Package Quantity: 1

94856838
BOLT, Fuel Injection, BOLT,FUEL INJECTION FUEL RAIL(M8X1.25X40)
- Require Quantity: 02
- Package Quantity: 1
- Replaced By: 94859968

94856839
SPACER, Fuel Injection, SPACER,FUEL INJECTION FUEL RAIL(8.5MM INSIDE DIAMETER, 20MM OUTSIDE DIAMETER)(27.6MM LONG)
- Require Quantity: 02
- Package Quantity: 1

94858779
SEAL, Fuel Injector, SEAL,FUEL INJECTOR(O RING)(PART OF 1)(1.9MM THICK)(7.8MM INSIDE DIAMETER, 11.6MM O.D.)(*01)
- Require Quantity: 04
- Package Quantity: 1

94858779
SEAL, Fuel Injector, SEAL,FUEL INJECTOR(O RING)(PART OF 24)(1.9MM THICK)(7.8MM INSIDE DIAMETER, 11.6MM O.D.)(*01)
- Require Quantity: 04
- Package Quantity: 1

94859505
INJECTOR, Fuel Injection, INJECTOR,MULTIPORT FUEL(INCLUDES 2)(INCLUDES SEAL)
- Require Quantity: 04
- Package Quantity: 1

94860014
INSULATOR, Fuel Injector, INSULATOR,FUEL INJECTOR(9MM INSIDE DIAMETER, 16MM OUTSIDE DIAMETER)(5.5MM HIGH)(*01)
- Require Quantity: 04
- Package Quantity: 1

Genuine GM Parts, the Right Choice

GMPartsGiant.com offers the wholesale prices for genuine 2004 Pontiac Vibe parts. Parts like Fuel Injection System are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 1.8L. Model Code: ALL PURPOSE 4 DOOR, ALL PURPOSE 4 DOOR AWD, ALL PURPOSE 4 DOOR GT.
