Manual Transmission Internal Gears fit your 2007 Pontiac Vibe

Currently shopping for

2007 Pontiac Vibe

Change Vehicle

Vehicle Options

4 Cyl 1.8L MFI; All Purpose 4 Door Vibe

Vehicle Options

4 Cyl 1.8L MFI; All Purpose 4 Door Vibe

Categories Close X

Currently selected

Transmission - Manual

Other Categories

Body Moldings, Sheet Metal, Rear Compartment Hardware, Roof Hardware

Body Mounting, Air Conditioning, Audio/Entertainment

Body Wiring, Roof Trim

Brakes

Brakes, Rear Axle, Propeller Shaft, Wheels, Tires

Cooling System, Grille, Oil System

Engine

Frames, Springs, Shocks, Bumpers, Fascias

Front End Sheet Metal, Heater

Front Suspension, Steering

Fuel System, Exhaust, Emission System

Interior Trim, Front Seat Trim, Seat Belts

Rear Glass, Seat Parts, Adjuster

Rear Seat Trim, Carpet

Starter, Generator, Ignition, Electrical, Lamps

Transmission - Automatic

Windshield, Wiper, Mirrors, Instrument Panel, Console, Doors

How to use OE catalog

Sort by:

Recommended

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

19205317
GEAR, Transmission First/Reverse Gear, GEAR,1ST(USED FROM PRODUCTION DATE 06/07)(1ST DESIGN 94851787)
$213.77 $33.58
1
Add To Cart

19205318
SHAFT, Transmission Mainshaft, SHAFT,MAIN
$280.61 $44.08
1
Add To Cart

19205344
SHAFT, Transmission Main Drive(Clutch), SHAFT,INPUT
$351.46 $119.96
1
Add To Cart

19205414
BEARING, Transmission Mainshaft Center/Rear, BEARING,MAIN SHAFT REAR
$86.97 $51.55
1
Add To Cart

19205438
RING, Transmission Synchronizer, RING,3RD GEAR BLOCKING
$70.00 $41.50
1
Add To Cart

88974553
HUB, Transmission Synchronizer, HUB,1ST & 2ND GEAR SYN
$132.25 $21.57
1
Add To Cart

94859756
RING, Transmission Synchronizer, RING,5TH GEAR BLOCKING
$37.92 $24.10
1
Add To Cart

19204255
GEAR,Fourth & Fifth Gear, GEAR,5TH(USED FROM PRODUCTION DATE 06/07)(1ST DESIGN 94859758)

19204256
GEAR, Transmission Second Speed, GEAR,2ND

19204257
HUB, Transmission Synchronizer, HUB,5TH GEAR SYN(USED FROM PRODUCTION DATE 06/07)(1ST DESIGN 94859091)

19204258
GEAR, Transmission Countershaft, GEAR,5TH COUNTER(USED FROM PRODUCTION DATE 06/07)(1ST DESIGN 94856641)

19205172
SLEEVE, Transmission Synchronizer, SLEEVE,3RD & 4TH GEAR SYN

19205242
HUB, Transmission Synchronizer, HUB,3RD & 4TH GEAR SYN

19205417
GEAR,Fourth & Fifth Gear, GEAR,4TH(USED FROM PRODUCTION DATE 06/07)(1ST DESIGN 88973202)

19205640
BEARING, Transmission Clutch Gear, BEARING,INPUT SHAFT REAR

88969249
BEARING, Transmission Mainshaft Center/Rear, BEARING,MAIN SHAFT FRONT(33MM INSIDE DIAMETER, 60MM 0D)(22MM HIGH)(*01)

88969271
RING SET, Transmission Main Shaft Gear, RING SET,2ND GEAR BLOCKING(INCLUDES: BLOCKING,MIDDLE,& INNER RING)

88973206
RING, Transmission Synchronizer, RING,4TH GEAR BLOCKING

88974084
RETAINER, Transmission Clutch Gear, RETAINER,INPUT & MAIN SHAFT BEARING

88974276
GEAR, Transmission Reverse Idler, GEAR,REV IDLER(INCLUDES BUSHING)

88974552
SLEEVE, Transmission Synchronizer, SLEEVE,5TH GEAR SYN

88974594
INSERT, Transmission Synchronizer, INSERT,1ST & 2ND GEAR SYN(WHEN SERVICING VEHICLES BUILT PRIOR TO PRODUCTION DATE 02/05, USE TOGETHER WITH SPRING 88974595)
- Require Quantity: 03
- Package Quantity: 1

88974595
SPRING, Transmission Synchronizer, SPRING,1ST & 2ND GEAR SYN INSERT(WHEN SERVICING VEHICLES BUILT PRIOR TO PRODUCTION DATE 02/05, USE TOGETHER WITH INSERT 88974594)
- Require Quantity: 03
- Package Quantity: 1

88974596
INSERT, Transmission Synchronizer, INSERT,3RD & 4TH GEAR SYN(USED TO SERVICE VEHICLES BUILT PRIOR TO PRODUCTION DATE 02/05)(USE TOGETHER WITH 88974597 SPRING AS A SET)
- Require Quantity: 03
- Package Quantity: 1

88974597
SPRING, Transmission Synchronizer, SPRING,3RD & 4TH GEAR SYN INSERT
- Require Quantity: 03
- Package Quantity: 1

88974598
INSERT, Transmission Synchronizer, INSERT,5TH GEAR SYN
- Require Quantity: 03
- Package Quantity: 1

88974664
GEAR, Transmission First/Reverse Gear, GEAR,REV

88975051
GEAR,Fifth & Sixth Gear, GEAR,3RD(USE TOGETHER WITH 88973336 3RD BLOCKING RING TO SERVICE 2003 VEHICLES WITH PRODUCTION DATE PRIOR TO 01/03.)

88975052
GEAR, Transmission Countershaft, GEAR,4TH COUNTER

94840434
BALL, Transmission First/Reverse Gear, BALL,1ST GEAR THRUST WASHER LOCATING(4.76MM DIAMETER)

94840708
BEARING, Transmission Gear, BEARING,1ST GEAR(38MM INSIDE DIAMETER, 44MM OUTSIDE DIAMETER)(26MM HIGH)

94840710
BEARING, Transmission Gear, BEARING,3RD GEAR(31MM INSIDE DIAMETER, 36MM OUTSIDE DIAMETER)(24.4MM HIGH)

94840712
BEARING, Transmission Gear, BEARING,5TH GEAR(24.9MM INSIDE DIAMETER, 29.9MM OUTSIDE DIAMETER)(26.8MM HIGH)

94840713
SPACER,Fourth & Fifth Gear, SPACER,5TH GEAR BEARING(25MM INSIDE DIAMETER, 29MM OUTSIDE DIAMETER)(2.5MM THICK)

94840716
RETAINER, Transmission Mainshaft, RETAINER,MAIN SHAFT BEARING

94840736
WASHER, Transmission Main Shaft Gear, WASHER,1ST GEAR THRUST(38.1MM INSIDE DIAMETER, 52MM OUTSIDE DIAMETER)(6MM THICK)

94840737
SPACER,Fifth & Sixth Gear, SPACER,3RD & 4TH COUNTER GEAR(43.5MM OUTSIDE DIAMETER, 28.7MM INSIDE DIAMETER)(24.9MM LONG)

94840738
SPACER, Transmission Mainshaft, SPACER,2ND GEAR BEARING(32.2MM INSIDE DIAMETER, 37MM OUTSIDE DIAMETER)(3.9MM THICK)

94840754
SPRING, Transmission Synchronizer, SPRING,5TH GEAR SYN(58.6MM OUTSIDE DIAMETER)
- Require Quantity: 02
- Package Quantity: 1

94842536
NUT, Transmission Countershaft Gear, NUT,5TH GEAR(M18X1.5)(*01)

94842875
BOLT, Transmission Reverse Idler Shaft, BOLT,REV IDLER GEAR SHAFT(M8X1.25X35)

94843201
SHAFT, Transmission Reverse Idler, SHAFT,REV IDLER GEAR

94843202
WASHER, Transmission Reverse Idler Gear, WASHER,REV IDLER GEAR THRUST(18.2MM INSIDE DIAMETER, 29MM OUTSIDE DIAMETER)(3.5MM THICK)

RING, Transmission Synchronizer

94843441
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE A)(2.25-2.30MM THICK)
94843442
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE B)(2.31-2.36MM THICK)
94843443
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE C)(2.37-2.42MM THICK)
94843444
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE D)(2.43-2.48MM THICK)
94843445
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE E)(2.49-2.54MM THICK)
94843446
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE F)(2.55-2.560MM THICK)
94843447
RING, 5TH GEAR SYN HUB THRUST(18MM INSIDE DIAMETER, 24MM O.D.)(CODE G)(2.61-2.66MM THICK)

RING, Transmission Clutch Gear

94843448
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE A)(2.29MM THICK)
94843449
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE B)(2.35MM THICK)
94843450
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE C)(2.41MM THICK)
94843451
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE D)(2.47MM THICK)
94843452
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE E)(2.53MM THICK)
94843453
RING, INPUT SHAFT REAR BEARING THRUST(22MM INSIDE DIAMETER, 28MM OUTSIDE DIAMETER)(CODE F)(2.59MM THICK)

RING, Transmission Synchronizer

94843460
RING, 1ST & 2ND GEAR SYN HUB RETAINER(CODE A)(2.50MM THICK)(36.6MM O.D., 29.2MM INSIDE DIAMETER)
94843461
RING, 1ST & 2ND GEAR SYN HUB RETAINER(CODE B)(2.56MM THICK)(36.6MM O.D., 29.2MM INSIDE DIAMETER)
94843463
RING, 1ST & 2ND GEAR SYN HUB RETAINER(CODE D)(2.68MM THICK)(36.6MM O.D.,29.2MM INSIDE DIAMETER)
94843464
RING, 1ST & 2ND GEAR SYN HUB RETAINER(CODE E)(2.74MM THICK)(36.6MM O.D., 29.2MM INSIDE DIAMETER)
94843465
RING, 1ST & 2ND GEAR SYN HUB RETAINER(CODE F)(2.80MM THICK)(36.6MM O.D., 29.2MM INSIDE DIAMETER)

94843470
RING, Transmission Mainshaft, RING,MAIN SHAFT REAR BEARING RETAINER(56.9MM INSIDE DIAMETER, 63.6MM OUTSIDE DIAMETER)(1.8MM THICK)

94843800
BEARING, Transmission Gear, BEARING,2ND GEAR(32MM INSIDE DIAMETER, 38MM OUTSIDE DIAMETER)(26.5MM HIGH)

94844003
BOLT, Transmission Case, BOLT,MANUAL TRANSMISSION OIL TROUGH(BOLT,HEXAGON(M8X1.25X12) HEADER POINT,W/LOCK WASHER(14.3MM DIAMETER)(8.900)

94844003
BOLT, Transmission Mainshaft, BOLT,MAIN SHAFT BEARING RETAINER((M8X1.25X12) HEADER POINT,W/ LOCK WASHER(14.3MM DIAMETER))(8.900)

94844301
BEARING, Transmission Clutch Gear, BEARING,INPUT SHAFT FRONT(25MM INSIDE DIAMETER, 43.5MM OUTSIDE DIAMETER)(15MM HIGH)(*01)

94844305
BEARING, Transmission Gear, BEARING,4TH GEAR(29MM INSIDE DIAMETER, 34MM OUTSIDE DIAMETER)(24.4MM HIGH)

94844306
SPACER,Fourth & Fifth Gear, SPACER,4TH GEAR BEARING(29.2MM INSIDE DIAMETER, 33.1MM OUTSIDE DIAMETER)(2.0MM THICK)

RING, Transmission Synchronizer

94844307
RING, 3RD & 4TH GEAR SYN HUB RETAINER(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 0)(2.30MM THICK)
94844308
RING, 3RD & 4TH GEAR SYN HUB RETAINER(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 1)(2.36MM THICK)
94844309
RING, 3RD & 4TH GEAR SYN HUB RETAINER(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 2)(2.42MM THICK)
94844310
RING, 3RD & 4TH GEAR SYN HUB RETAINER(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 3)(2.48MM THICK)
94844311
RING, 3RD & 4TH GEAR SYN HUB RETAINER(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 4)(2.54MM THICK)
94844312
RING, 3RD & 4TH GEAR SYN HUB RETAINER(26.6MM INSIDE DIAMETER, 34.8MM OUTSIDE DIAMETER)(CODE 5)(2.60MM THICK)

94845631
GEAR, Transmission Countershaft, GEAR,3RD COUNTER

94846128
WASHER, Transmission Reverse Idler Gear, WASHER,REV IDLER GEAR SHAFT(8.3MM INSIDE DIAMETER, 16.5MM OUTSIDE DIAMETER)(2.0MM THICK)(*01)

94851619
BOLT, Transmission Clutch Gear, BOLT,INPUT & MAIN SHAFT BEARING RETAINER(M8X1.25X20)(CONTAINS WASHER-14.3MM O.D.)
- Require Quantity: 05
- Package Quantity: 1

94855309
SHIELD, Transmission Mainshaft Center/Rear, SHIELD,MAIN SHAFT BEARING OIL

94855903
TROUGH, Transmission Case, TROUGH,MANUAL TRANSMISSION OIL

94859752
RING, Transmission Synchronizer, RING,1ST GEAR BLOCKING

Genuine GM Parts, the Right Choice

GMPartsGiant.com offers the wholesale prices for genuine 2007 Pontiac Vibe parts. Parts like Manual Transmission Internal Gears are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 1.8L. Model Code: ALL PURPOSE 4 DOOR.
