Part No. & Part Description
Price
Part No. &
Part Description
SEAL, Engine Front Cover & Crankshaft Seal
12585673SEAL, CRANKSHAFT FRONT OIL(*KIT1)
- Fitting Vehicle Options:
KJ,KM,KN(LTA,MHW)
12626923SEAL, CRANKSHAFT FRONT OIL(PART OF 300)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
12626923SEAL, CRANKSHAFT FRONT OIL
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
12654010SEAL, CRANKSHAFT FRONT OIL(PART OF 1)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12693989SEAL, CRANKSHAFT FRONT (O RING)
- Fitting Vehicle Options:
KH,KJ,KL(LSY,MHS,NTB,NUC,NUP)
BOLT, Turbocharger/Supercharger Cooling
11588712BOLT, CHARGING AIR COOLER COOLANT INLET PIPE(M6X1X20,17.5THD)(14.2 OUTSIDE DIAMETER,8.8 GMW3359)(M-POINT)(8.900)
11548167BOLT, CHARGING AIR COOLER COOLANT OUTLET PIPE(PART OF 32)(M5X1X35)
SEAL, Engine Coolant Thermostat Housing
12587397SEAL, WATER INLET(*KIT1)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12647400SEAL, WATER INLET(*KIT1)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12647181SEAL, ENGINE COOLANT THERMOSTAT HOUSING(PART OF 6)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12687167VALVE, CAMSHAFT POSITION ACTUATOR SOLENOID
- Fitting Vehicle Options:
KJ,KM,KN69(LTA)
- Require Quantity:
04
- Package Quantity:
1
- Replaced By:
12732244
12647904VALVE, CAMSHAFT POSITION ACTUATOR LOCATING PINION CONTROL
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Require Quantity:
02
- Package Quantity:
1
11561619BOLT, M8X1.25 6H 43.0, GMW25 (8.8) STEEL, GMW3179 CODE C(TIMING CHAIN GUIDE)(8.900)
11561619BOLT, M8X1.25 6H 43.0, GMW25 (8.8) STEEL, GMW3179 CODE C(TIMING CHAIN GUIDE)(*KIT1)(8.900)
- Require Quantity:
03
- Package Quantity:
1
11547061BOLT, TIMING CHAIN GUIDE(PART OF 17)(M6X1X30)(HEX FLANGED HEAD)(DISHED HEAD)(0.206)
- Fitting Vehicle Options:
KH,KJ,KL69(LSY)
11547061BOLT, TIMING CHAIN TENSIONER(PART OF 11)(M6X1X30)(HEX FLANGED HEAD)(DISHED HEAD)(0.206)
- Fitting Vehicle Options:
KH,KJ,KL69(LSY)
- Require Quantity:
02
- Package Quantity:
1
11548169BOLT, TIMING CHAIN GUIDE(M6X1X17)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
11548177BOLT, TIMING CHAIN GUIDE(M8X1.25X25)(1.639)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
04
- Package Quantity:
1
11549151BOLT, TIMING CHAIN TENSIONER SHOE(M8X1.25X43)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
02
- Package Quantity:
1
11610726BOLT, TIMING CHAIN TENSIONER SHOE(PART OF 29)(M8X1.25X44)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
11612158BOLT, TIMING CHAIN TENSIONER(PART OF 6)(*KIT1,KIT2,KIT3,KIT4,KIT5)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Require Quantity:
02
- Package Quantity:
1
11548178BOLT, TIMING CHAIN TENSIONER(PART OF 8,14)(M8X1.25X35.7MM)(0.459)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
02
- Package Quantity:
1
11588327RETAINER, TIMING CHAIN(PART OF 7)(ROUND M8 BOLT)(4.128)
- Fitting Vehicle Options:
KL(LTG,HP9)
- Require Quantity:
02
- Package Quantity:
1
11588327RETAINER, TIMING CHAIN TENSIONER BOLT(PART OF 25)(ROUND M8 BOLT)(4.128)
- Fitting Vehicle Options:
KL(LTG,HP9)
- Require Quantity:
02
- Package Quantity:
1
11588327RETAINER, TIMING CHAIN TENSIONER BOLT(PART OF 8,14)(ROUND M8 BOLT)(4.128)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
02
- Package Quantity:
1
11518792RETAINER, TIMING CHAIN GUIDE BOLT(PART OF 17)(7MM LONG)(FOR M6 BOLT)(1.428)
- Fitting Vehicle Options:
KH,KJ,KL69(LSY)
11518792RETAINER, TIMING CHAIN TENSIONER BOLT(PART OF 11)(7MM LONG)(FOR M6 BOLT)(1.428)
- Fitting Vehicle Options:
KH,KJ,KL69(LSY)
- Require Quantity:
02
- Package Quantity:
1
90530642CLAMP, ENGINE OIL COOLER COOLANT OUTLET HOSE(PART OF 311,313)(CLAMP-SPRINDBAND, 14X12, DOUBLE BAND)(3.337)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
11547607CLAMP, ENGINE OIL COOLER COOLANT INLET HOSE(PART OF 18)(GRAY)(23X12)(CLAMP-SPRINGBAND)(8.846)
- Fitting Vehicle Options:
KN69, KH,KJ,KL,KM69
- Replaced By:
11570871
12627107CHAIN, CAMSHAFT TIMING
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
12647895CHAIN, CAMSHAFT TIMING(CAMSHAFT DRIVE CHAIN)(*KIT1)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Require Quantity:
02
- Package Quantity:
1
12666061CHAIN, CAMSHAFT TIMING
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
02
- Package Quantity:
1
12694716CHAIN, CAMSHAFT TIMING(OIL PUMP DRIVE CHAIN)(*KIT1)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
55514729CHAIN, CAMSHAFT TIMING
- Fitting Vehicle Options:
KH,KJ69(LSY)
12627111GUIDE, TIMING CHAIN(INCLUDES 19,20)(W/BOLT, SCREW, & RETAINER)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
12627184GUIDE, TIMING CHAIN(W/O BOLT, SCREW, & RETAINER)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
12647880GUIDE, TIMING CHAIN(PIVOT GUIDE)(*KIT1)
- Location:
Driver Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Replaced By:
12713643
12647881GUIDE, TIMING CHAIN(PIVOT GUIDE)(*KIT1)
- Location:
Passenger Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Replaced By:
12713644
12647884GUIDE, TIMING CHAIN((INCLUDES 5,6))(SECONDARY)(INCLUDES BOLTS & RETAINER)
- Location:
Driver Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12647885GUIDE, TIMING CHAIN(INCLUDES 5)(SECONDARY)(W/O BOLTS & RETAINER)(*KIT1,KIT3)
- Location:
Driver Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Replaced By:
12713647
12665676GUIDE, TIMING CHAIN(INCLUDES 5,18)(SECONDARY)(INCLUDES BOLTS & RETAINER)
- Location:
Passenger Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12666054GUIDE, TIMING CHAIN
- Location:
Driver Side
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12666056GUIDE, TIMING CHAIN
- Location:
Passenger Side
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12713648GUIDE, TIMING CHAIN(SECONDARY)(W/O BOLTS & RETAINER)(*KIT1,KIT2)
- Location:
Passenger Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
55496987GUIDE, TIMING CHAIN(INCLUDES 12,13)(W/RETAINER & BOLT)(PRIMARY FIXED TIMING CHAIN)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
55496988GUIDE, TIMING CHAIN(W/O RETAINER OR BOLT)(PRIMARY PIVOT TIMING CHAIN)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
55505568GUIDE, TIMING CHAIN(CAM TO CAM TIMING CHAIN)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
RETAINER, Engine Front Cover
11518792RETAINER, ENGINE FRONT COVER(7MM LONG)(FOR M6 BOLT)(*KIT1)(1.428)
- Fitting Vehicle Options:
KH,KJ,KL69(LSY)
11518792RETAINER, ENGINE FRONT COVER BOLT(7MM LONG)(FOR M6 BOLT)(1.428)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
25
- Package Quantity:
1
11548882RETAINER, ENGINE FRONT COVER(PART OF 1)(PLASTIC TREE)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Require Quantity:
04
- Package Quantity:
1
11547061BOLT, ENGINE FRONT COVER(M6X1X30)(HEX FLANGED HEAD)(DISHED HEAD)(*KIT1)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
11547649BOLT, ENGINE FRONT COVER(PART OF 1)(M6X1X30MM)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Require Quantity:
09
- Package Quantity:
1
11547903BOLT, ENGINE FRONT COVER(PART OF 300)(M10X1.5X45)(15 SOCKET,22.3 OUTSIDE DIAMETER,INDENTED HEAD)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
- Require Quantity:
02
- Package Quantity:
1
11547904BOLT, ENGINE FRONT COVER(PART OF 300)(M10X1.5X52)(15 SOCKET,22.3 OUTSIDE DIAMETER,INDENTED HEAD)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
11548002BOLT, ENGINE FRONT COVER(M5X0.8X17)(1.428)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
- Require Quantity:
09
- Package Quantity:
1
11548003BOLT, TIMING BELT UPPER COVER(M5X0.8X25)(1.780)
- Fitting Vehicle Options:
KH,KJ,KL69(LSY)
- Require Quantity:
11
- Package Quantity:
1
11548170BOLT, ENGINE FRONT COVER(M6X1X38)(10 MM SOCKET)(1.652)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
18
- Package Quantity:
1
11548171BOLT, ENGINE FRONT COVER(PART OF 1)(M6X1X43,10)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Require Quantity:
16
- Package Quantity:
1
11548172BOLT, ENGINE FRONT COVER(M6X1X63)(3.373)
- Fitting Vehicle Options:
KJ,KM,KN69(LTA)
- Require Quantity:
02
- Package Quantity:
1
11548174BOLT, ENGINE FRONT COVER(M6X1X73)(0.413)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
11548294BOLT, ENGINE FRONT COVER(M6X1X118,10)
- Fitting Vehicle Options:
KJ,KM,KN(LTA,MHW)
- Require Quantity:
02
- Package Quantity:
1
11548395BOLT, ENGINE FRONT COVER(M6X1X88)
- Fitting Vehicle Options:
KJ,KM,KN(LTA,MHW)
- Require Quantity:
02
- Package Quantity:
1
22531637PIN, ENGINE FRONT COVER LOCATING(PART OF 1)(8MM DIAMETER,12MM LONG)(DOWEL)(0.413)
- Fitting Vehicle Options:
KJ,KL,KM69(LGW), KH,KJ,KL,KM69(LGX)
- Require Quantity:
02
- Package Quantity:
10
12625107PIN, ENGINE FRONT COVER LOCATING(0.669)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
03
- Package Quantity:
1
12668731PIN, ENGINE FRONT COVER LOCATING(6MM DIAMETER)(PINION-6 OUTSIDE DIAMETER,17 LONG)(*KIT1)(0.137)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
- Require Quantity:
02
- Package Quantity:
1
12668731PIN, ENGINE FRONT COVER LOCATING(6MM DIAMETER)(PINION-6 OUTSIDE DIAMETER,17 LONG)(0.137)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
- Require Quantity:
02
- Package Quantity:
1
22531637PIN, WATER PUMP LOCATING(PART OF 1)(8MM DIAMETER,12MM LONG)(DOWEL)(0.413)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM69(LGX)
- Require Quantity:
02
- Package Quantity:
10
12625107PIN, WATER PUMP LOCATING(PART OF 38)(0.669)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
02
- Package Quantity:
1
SPROCKET, Engine Crankshaft/Timing
12647897SPROCKET, CRANKSHAFT(FRONT & REAR)(*KIT1)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Require Quantity:
02
- Package Quantity:
1
12647898SPROCKET, CRANKSHAFT(FRONT ONLY)(*KIT1)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12681327SPROCKET, CRANKSHAFT(INCLUDES 11,13)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12627109TENSIONER, TIMING CHAIN(INCLUDES 24,26,27)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
12647893TENSIONER, TIMING CHAIN(FOR OIL PUMP CHAIN)(W/O GASKET, BOLTS, & RETAINERS)(*KIT1)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Replaced By:
12713638
12674626TENSIONER, TIMING CHAIN(INCLUDES 5,14,15)(W/RETAINER, GASKET, AND BOLT)
- Location:
Passenger Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Replaced By:
12713641
12674627TENSIONER, TIMING CHAIN(INCLUDES 5,19,20)(W/RETAINER, GASKET, AND BOLT)
- Location:
Driver Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Replaced By:
12713642
12691835TENSIONER, TIMING CHAIN(INCLUDES 7,9)
- Location:
Driver Side
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12691836TENSIONER, TIMING CHAIN(INCLUDES 7,9)
- Location:
Passenger Side
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12713639TENSIONER, TIMING CHAIN(INCLUDES RETAINER W/O BOLTS AND GASKET)(*KIT1,KIT4)
- Location:
Passenger Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12713640TENSIONER, TIMING CHAIN(INCLUDES RETAINER W/O BOLTS AND GASKET)(*KIT1,KIT5)
- Location:
Driver Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
55506835TENSIONER, TIMING CHAIN(INCLUDES 10,14)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
- Replaced By:
12709437
GASKET, Engine Coolant Pump
25201460GASKET, WATER PUMP(PART OF 328)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9,NT7,NU5)
12646995GASKET, WATER PUMP HOUSING(PART OF 1)(*KIT2)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12666921GASKET, WATER PUMP HOUSING(PART OF 38)(*KIT1)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
25201453GASKET, WATER PUMP INLET(PART OF 328)
- Fitting Vehicle Options:
KH,KJ,KL(LTG), KL(LTG)
SEAL, Radiator Outlet (Lower)
12649985SEAL, WATER OUTLET(PART OF 3)(RWD)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12671039SEAL, WATER OUTLET(PART OF 6)(*KIT1)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
PULLEY, Fan and Coolant Pump
12652047PULLEY, WATER PUMP
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12662711PULLEY, WATER PUMP(PART OF 328)
- Fitting Vehicle Options:
KL(LTG)
SENSOR, Coolant Temperature (Engine Unit)
25186240SENSOR, ENGINE COOLANT TEMPERATURE(PART OF 6)
- Fitting Vehicle Options:
KN69(LTA,MHW), KH,KJ,KL,KM69(LTA,MHW)
12656444SENSOR, ENGINE COOLANT TEMPERATURE(PART OF 303)(INCLUDES 304)(GOLD)(PLATED CONNECTOR)(PART OF THERMOSTAT HOUSING ON ENGINE)
- Fitting Vehicle Options:
KL69(LTG,MRT)
HOUSING, Engine Coolant Thermostat
12671038HOUSING, ENGINE COOLANT THERMOSTAT(INCLUDES 49)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
25201447HOUSING, ENGINE COOLANT THERMOSTAT(INCLUDES 322,325)(PART OF 328)(INCLUDES HOUSING, THERMOSTAT, AND GASKET)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
12678784HOUSING, ENGINE COOLANT THERMOSTAT(INCLUDES 5,7)
- Fitting Vehicle Options:
KJ,KL,KM69(LGW,MHS), KH,KJ,KL,KM69(LGX)
COVER, Engine Front Cover
25203062COVER, ENGINE FRONT(W/CRANKSHAFT FRONT OIL SEAL)(INCLUDES 144,331-341)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9,NT7,NU5)
12698470COVER, ENGINE FRONT (W/ WATER PUMP)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12704638COVER, ENGINE FRONT (W/ WATER PUMP)(INCLUDES 8-12,18-24,27-29,33,35)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Replaced By:
12729377
55506833COVER, TIMING BELT UPPER FRONT(INCLUDES 3,4,6,28-31)
- Fitting Vehicle Options:
KH,KJ,KL69(LSY)
11547603BOLT, WATER OUTLET(PART OF 6)(M6X1X25)(1.079)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
02
- Package Quantity:
1
11547603BOLT, WATER PUMP HOUSING(PART OF 38)(M6X1X25)(1.079)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
06
- Package Quantity:
1
11547603BOLT, WATER INLET(PART OF 1)(M6X1X25)(1.079)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
02
- Package Quantity:
1
11611106BOLT, WATER OUTLET(PART OF 303)(M6X1X34)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
- Require Quantity:
02
- Package Quantity:
1
11611106BOLT, WATER OUTLET(PART OF 3)(M6X1X34)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Require Quantity:
02
- Package Quantity:
1
11547603BOLT, CAMSHAFT POSITION ACTUATOR SOLENOID VALVE(M6X1X25)(1.079)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
04
- Package Quantity:
1
11549342BOLT, CAMSHAFT POSITION ACTUATOR VALVE SOLENOID(M5X0.8X21)(HEXAGON HEAD)
- Fitting Vehicle Options:
KH,KJ,KL69(LSY)
- Require Quantity:
04
- Package Quantity:
1
11588844BOLT, CAMSHAFT POSITION ACTUATOR(M10X1.5X76, 19 THREAD)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
- Require Quantity:
02
- Package Quantity:
1
11612172BOLT, CAMSHAFT POSITION ACTUATOR
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Require Quantity:
04
- Package Quantity:
1
11612172BOLT, CAMSHAFT POSITION ACTUATOR
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
55512050BOLT, CAMSHAFT SPROCKET (W/ACTUATOR VALVE)
- Fitting Vehicle Options:
KH,KJ,KL(LSY,MHS,NTB,NUC,NUP)
- Require Quantity:
02
- Package Quantity:
1
BOLT, Engine Crankshaft Pulley and Balancer
11548686BOLT, CRANKSHAFT BALANCER(M16X2X85)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
12557840BOLT, CRANKSHAFT BALANCER(M16X2.0X103)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
HOSE, Engine Coolant By-Pass
12627054HOSE, THERMOSTAT BYPASS(PART OF 303)(INCLUDES 308)(12MM RADIUS)
12683114HOSE, THERMOSTAT BYPASS(PART OF 311)(INCLUDES 312,314)(4MM RADIUS)
SEAL, Engine Coolant Pump
12649987SEAL, WATER PUMP OUTLET PORTION(PART OF 1)
- Require Quantity:
02
- Package Quantity:
1
GASKET, Engine Front Cover
12647888GASKET, TIMING CHAIN HOUSING(*KIT1,KIT4)
- Location:
Passenger Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12647891GASKET, TIMING CHAIN HOUSING(*KIT1,KIT5)
- Location:
Driver Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12686210GASKET, ENGINE FRONT COVER(*KIT1)
- Location:
Driver Side
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12686211GASKET, ENGINE FRONT COVER(*KIT1)
- Location:
Passenger Side
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12686212GASKET, ENGINE FRONT COVER(UPPER)(*KIT1)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12650468OUTLET, WATER(INCLUDES 2,4)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12671845OUTLET, WATER(INCLUDES 302,304-310)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9,NT7,NU5)
12688674OUTLET, WATER(INCLUDES 4,5,7)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12653143SEAL, CAMSHAFT POSITION ACTUATOR SOLENOID VALVE(O RING)(PART OF 1)(FRONT COVER)
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Require Quantity:
02
- Package Quantity:
1
12653143SEAL, CAMSHAFT POSITION ACTUATOR SOLENOID VALVE(FRONT COVER)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
04
- Package Quantity:
1
12653143SEAL, CAMSHAFT POSITION ACTUATOR SOLENOID VALVE(O RING)(FRONT COVER)(*KIT1)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
08
- Package Quantity:
1
BALANCER, Engine Crankshaft And Camshaft Balancer
12662709PUMP, WATER(INCLUDES 317,318,320-327,329,330)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9,NT7,NU5)
12686208PUMP, WATER(INCLUDES 28,29,39)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
ACTUATOR, Engine Camshaft
12666062ACTUATOR, CAMSHAFT POSITION INTAKE
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
- Require Quantity:
02
- Package Quantity:
1
- Replaced By:
12694536
12666063ACTUATOR, CAMSHAFT POSITION EXHAUST
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
12666665ACTUATOR, CAMSHAFT POSITION(INTAKE)
- Location:
Passenger Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
- Replaced By:
12690958
12684805ACTUATOR, CAMSHAFT POSITION(EXHAUST)
- Location:
Passenger Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12684806ACTUATOR, CAMSHAFT POSITION(EXHAUST)
- Location:
Driver Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
12690959ACTUATOR, CAMSHAFT POSITION(INTAKE)
- Location:
Driver Side
- Fitting Vehicle Options:
KJ,KL,KM(LGW), KH,KJ,KL,KM(LGX)
25203205ACTUATOR, CAMSHAFT POSITION(EXHAUST)(FOR CONNECTOR USE 13587326)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
25203207ACTUATOR, CAMSHAFT POSITION(INTAKE)
- Fitting Vehicle Options:
KL(LTG,MRT,HP9)
PIPE, Engine Coolant Pump
12668440PIPE, WATER PUMP INLET(INCLUDES 14-16)(INCLUDES BOLTS, RETAINERS & SEAL)
12706857PIPE, WATER PUMP INLET(W/O BOLTS, RETAINERS, OR SEAL)(*KIT1)
12694157SEAL, ENGINE FRONT COVER(INCLUDES 2,5,8,9,19,26,39,42)
- Fitting Vehicle Options:
KJ,KM,KN(LTA)
55506816SEAL, TIMING BELT FRONT UPPER COVER(*KIT1)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
SPROCKET, Engine Camshaft
55509050SPROCKET, CAMSHAFT INTAKE (W/CAMSHAFT POSITION ACTUATOR)
- Fitting Vehicle Options:
KH,KJ,KL(LSY)
- Replaced By:
55512053
55512051SPROCKET, CAMSHAFT EXHAUST (W/CAMSHAFT POSITION ACTUATOR)
- Fitting Vehicle Options:
KH,KJ,KL69(LSY)
90572595CLAMP,A/C), CLAMP,THERMOSTAT BYPASS HOSE(PART OF 303,309)(32 DIAMETER X 12 WIDE)(8.846)
Standard Parts
11588714BOLT, HEX FLANGED HEAD,M6X1X30,22.7 THREAD,14.2 OUTSIDE DIAMETER,8.8,GMW3359, M-POINT.(PART OF 311)
- Require Quantity:
02
- Package Quantity:
1
11588714BOLT, HEX FLANGED HEAD,M6X1X30,22.7 THREAD,14.2 OUTSIDE DIAMETER,8.8,GMW3359, M-POINT.(PART OF 328)
- Require Quantity:
04
- Package Quantity:
1
11588714BOLT, HEX FLANGED HEAD,M6X1X30,22.7 THREAD,14.2 OUTSIDE DIAMETER,8.8,GMW3359, M-POINT.(CAMSHAFT COVER)
- Require Quantity:
19
- Package Quantity:
1
11588714BOLT, HEX FLANGED HEAD,M6X1X30,22.7 THREAD,14.2 OUTSIDE DIAMETER,8.8,GMW3359, M-POINT.(PART OF 300)
11588714BOLT, HEX FLANGED HEAD,M6X1X30,22.7 THREAD,14.2 OUTSIDE DIAMETER,8.8,GMW3359, M-POINT.(PART OF 328)
- Require Quantity:
02
- Package Quantity:
1
11588712BOLT, HEX FLANGED HEAD,M6X1X20,17.5 THREAD,14.2 O.D.,8.8, GMW3359(CAMSHAFT POSITION ACTUATOR SOLENOID VALVE)
- Require Quantity:
02
- Package Quantity:
10
11588712BOLT, HEX FLANGED HEAD,M6X1X20,17.5 THREAD,14.2 O.D.,8.8, GMW3359(ENGINE OIL COOLER COOLANT HOSE)
11561026BOLT, HEX FLANGED HEAD,THREAD,14.2 OUTSIDE DIAMETER,9.8,GMW3200,MACHINE,HEADER POINT(TIMING CHAIN GUIDE)
11588715BOLT, HEX FLANGED HEAD,M6X1X35,18 THREAD,14.2 OUTSIDE DIAMETER,8.8,GMW3359,5MM M POINT(PART OF 300)
- Require Quantity:
02
- Package Quantity:
1
11588715BOLT, HEX FLANGED HEAD,M6X1X35,18 THREAD,14.2 OUTSIDE DIAMETER,8.8,GMW3359,5MM M POINT(PART OF 13)
- Require Quantity:
02
- Package Quantity:
1
11588725BOLT, HEX FLANGED HEAD,M8X1.25X35,25 THREAD,18 OUTSIDE DIAMETER,8.8 STEEL,GMW3359,M-POINT(PART OF 328)
- Require Quantity:
03
- Package Quantity:
1
11588725BOLT, HEX FLANGED HEAD,M8X1.25X35,25 THREAD,18 OUTSIDE DIAMETER,8.8 STEEL,GMW3359,M-POINT(PART OF 300)
- Require Quantity:
13
- Package Quantity:
1
11588725BOLT, HEX FLANGED HEAD,M8X1.25X35,25 THREAD,18 OUTSIDE DIAMETER,8.8 STEEL,GMW3359,M-POINT(PART OF 7)
- Require Quantity:
02
- Package Quantity:
1
11588725BOLT, HEX FLANGED HEAD,M8X1.25X35,25 THREAD,18 OUTSIDE DIAMETER,8.8 STEEL,GMW3359,M-POINT(PART OF 25)
- Require Quantity:
02
- Package Quantity:
1
11588725BOLT, HEX FLANGED HEAD,M8X1.25X35,25 THREAD,18 OUTSIDE DIAMETER,8.8 STEEL,GMW3359,M-POINT(OIL PAN)
- Require Quantity:
08
- Package Quantity:
1
11588713BOLT, HEX FLANGED HEAD M6X1X25,21.5 THREAD,14.2 OUTSIDE DIAMETER,8.8,7114M,MACHINE,HEADER POINT(WATER PUMP INLET PIPE)(*KIT1)
- Require Quantity:
02
- Package Quantity:
1
11589278BOLT, HEX FLANGED HEAD,M12X1.75X75.9,45 THREAD,26.6 OUTSIDE DIAMETER,10.9,GMW3359,REDUCED BODY(ENGINE FRONT COVER)
11588694BOLT, HEXAGON-HEAD,M8X1.25X120.8,DOG POINT,8.8,GMW3359(OIL PAN)
- Require Quantity:
05
- Package Quantity:
1
11588940BOLT, HEXAGON HEAD, W/CONICAL SPRING WASHER,M6X1X14.55,8.45 THREAD,13.3O.D.,8.8.GMW3359(WATER PUMP PULLEY)
- Require Quantity:
04
- Package Quantity:
1
11589275BOLT, HEX FLANGED HEAD, M12X1.75X50.8, 40.45 THREAD,26.6 OUTSIDE DIAMETER, 10.9, GMW3359, M-POINT.(ENGINE FRONT COVER)
11519174BOLT, HEX FLANGED HEAD,W/REDUCED BODY,M8X1.25X65,THREAD 22,O.D. 18,8.8,GMW3359(ENGINE FRONT COVER)
- Require Quantity:
02
- Package Quantity:
1
11588719BOLT, HEX FLANGED HEAD,M6X1X60,18MM THREAD,14.2 O.D.,8.8,3359GMW(PART OF 6)
- Require Quantity:
02
- Package Quantity:
1
Genuine GM Parts, the Right Choice
GMPartsGiant.com offers the wholesale prices for genuine 2019
Cadillac CT6 parts. Parts like Engine Assembly-Front Cover, Timing Chain & Tensioner & Cooling are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 2.0L, 6 Cyl 3.0L, 6 Cyl 3.6L, 8 Cyl 4.2L. Model Code: 4 DOOR SEDAN, BASE 4 DOOR SEDAN, PLATINUM 4 DOOR SEDAN, PREMIUM 4 DOOR SEDAN, V-SPORT 4 DOOR SEDAN.
24504031
55575090
24100002
MSRP: $22.67$14.411
MSRP: $52.95$31.991
MSRP: $43.84$26.491
MSRP: $24.49$15.591
MSRP: $14.46$9.191
MSRP: $31.11$19.771
MSRP: $210.83$106.251
MSRP: $8.60$5.461
12630780
12639042
MSRP: $98.03$61.481
25702230
11588940
11610952
MSRP: $7.03$4.241
MSRP: $8.18$4.351
MSRP: $15.32$9.731
MSRP: $62.65$34.921
MSRP: $7.03$4.461
MSRP: $12.18$7.741
MSRP: $56.64$30.021
12689082
12690487
12698812
19369831
55486668
MSRP: $5.73$3.631
MSRP: $12.30$6.861
11561583
90572587
