Engine Assembly-Oil Pump, Pan & Related Parts fit your 2005 Pontiac Bonneville

Currently shopping for

2005 Pontiac Bonneville

Change Vehicle

Categories Close X

Currently selected

Engine

Other Categories

Body Moldings, Sheet Metal, Rear Compartment Hardware, Roof Hardware

Body Mounting, Air Conditioning, Audio/Entertainment

Brakes

Brakes, Rear Axle, Propeller Shaft, Wheels, Tires

Cooling System, Grille, Oil System

Frames, Springs, Shocks, Bumpers, Fascias

Front End Sheet Metal, Heater

Front Suspension, Steering

Fuel System, Exhaust, Emission System

Interior Trim, Front Seat Trim, Seat Belts

Maintenance Parts, Fluids, Capacities, Electrical Connectors

Rear Glass, Seat Parts, Adjuster

Rear Seat Trim, Carpet

Starter, Generator, Ignition, Electrical, Lamps

Transmission - Automatic

Windshield, Wiper, Mirrors, Instrument Panel, Console, Doors

How to use OE catalog

Sort by:

Recommended

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

24504031
SEAL, Engine Oil Level, SEAL,OIL LEVEL INDICATOR TUBE(O RING)(PART OF 416)(6.07 INSIDE DIAMETER; 1.78 DIAMETER)
$17.88 $10.80
1
Add To Cart

24504031
SEAL, Engine Oil Level, SEAL,OIL LEVEL INDICATOR(O RING)(PART OF 417)(6.07 INSIDE DIAMETER; 1.78 DIAMETER)
$17.88 $10.80
1
Add To Cart

24504031
SEAL, Engine Oil Level, SEAL,OIL LEVEL INDICATOR(O RING)(PART OF 430)(6.07 INSIDE DIAMETER; 1.78 DIAMETER)
$17.88 $10.80
1
Add To Cart

24504031
SEAL, Engine Oil Level, SEAL,OIL LEVEL INDICATOR TUBE(O RING)(PART OF 431)(6.07 INSIDE DIAMETER; 1.78 DIAMETER)
$17.88 $10.80
1
Add To Cart

12603782
SWITCH, Engine Oil Level, SWITCH,ENGINE OIL LEVEL INDICATOR(INCLUDES 715)(STRAIGHT ELECTRODE CONNECT)(MATING CONNECT W/LEADS USE 12102747)
$47.81 $28.89
1
Add To Cart

12581570
GASKET, Engine Oil Pump Inlet, GASKET,OIL PUMP SCREEN(SUCTION PIPE FLANGE)
$15.83 $9.92
10
Add To Cart

12574822
INDICATOR, Engine Oil Level, INDICATOR,OIL LEVEL(INCLUDES 422)

11562588
PLUG, Engine Oil Pan Drain, PLUG,OIL PAN DRAIN(PART OF 400)(INCLUDES 404)(M12X1.75X25)(W/SEAL)(EXCEPT MAGNET)(W/HEXAGON HEAD)
$12.65 $7.63
10
Add To Cart

11562588
PLUG, Engine Oil Pan Drain, PLUG,OIL PAN DRAIN(PART OF 400)(INCLUDES 413)(M12X1.75X25)(W/SEAL)(EXCEPT MAGNET)(W/HEXAGON HEAD)
$12.65 $7.63
10
Add To Cart

24505433
GEAR SET, Engine Oil Pump, GEAR SET,OIL PUMP(CONSISTS OF INNER & OUTER GEROTOR PUMP GEARS)(INCLUDES 900)
$28.96 $21.07
1
Add To Cart

25014612
VALVE, Engine Oil Filter, VALVE,OIL FILTER BYPASS(W/O VAPOR SEPARATOR)(OPENING PRESSURE 21 PSI NOMINAL)(PART HAS A 16.10MM MAX OUTSIDE DIAMETER & FITS A 15.84 HOLE IN BLOCK)
$10.08 $5.34
1
Add To Cart

25014612
VALVE, Engine Oil Filter, VALVE,OIL FILTER BYPASS(PART OF 440)(W/O VAPOR SEPARATOR)(OPENING PRESSURE 21 PSI NOMINAL)(PART HAS A 16.10MM MAX OUTSIDE DIAMETER & FITS A 15.84 HOLE IN BLOCK)
$10.08 $5.34
1
Add To Cart

25534742
GASKET, Engine Oil Filter, GASKET,OIL FILTER ADAPTER
$31.65 $19.84
5
Add To Cart

12581822
MANIFOLD, Engine Oil Distribution, MANIFOLD,ENGINE OIL(INCLUDES 107)
$290.68 $183.92

3538288
BOLT, Engine Oil Pump, BOLT,OIL PUMP(HEX FLANGED HEAD,M8X1.75X55)
- Require Quantity: 03
- Package Quantity: 1
$5.74 $3.65

12573044
GASKET, Engine Oil Filter, GASKET,OIL FILTER ADAPTER(PART OF 440)
$11.55 $7.24
5
Add To Cart

24575062
FITTING, Engine Oil Filter, FITTING,OIL FILTER ADAPTER(PART OF 440)
$13.50 $8.46
1
Add To Cart

3542310
BOLT, Engine Oil, BOLT,LOWER CRANKCASE(M10X1.5X125,30 THREAD)(8.900)
- Require Quantity: 19
- Package Quantity: 5
$11.88
5
Add To Cart

25521935
COVER, Engine Oil Pump, COVER,OIL PUMP

11610052
BOLT, Plug Threaded, BOLT,OIL PAN(TO CYL BLOCK)(1.428)
- Require Quantity: 20
- Package Quantity: 1
$9.79 $6.22
1
Add To Cart

12552623
SEAL, Engine Oil Filter, SEAL,OIL FILTER ADAPTER(O RING)(PART OF 440)
$2.82 $1.93
10
Add To Cart

PAN, Engine Oil
12564803
PAN, OIL(INCLUDES 412,413)(LESS GASKET & SENSOR)(USE ROOM TEMPERATURE VULCANIZING)
Fitting Vehicle Options: H(LD8)
$586.50 $408.03
1
Add To Cart
12587389
PAN, OIL(INCLUDES 403,404,420,421)(HAS GROOVE FOR ROOM TEMPERATURE VULCANIZING NO GASKET REQUIRED)
- Fitting Vehicle Options: H(L36)

12603784
SWITCH, Engine Oil Level, SWITCH,ENGINE OIL LEVEL INDICATOR(INCLUDES 713)(135.8X28.7)
$70.70 $44.34
1
Add To Cart

3542311
STUD, Engine Oil, STUD,LOWER CRANKCASE(M10X1.5X125-M9X1.0X13)(1.428)
$7.02 $4.46
5
Add To Cart

12555384
PUMP, Engine Oil Pump, PUMP,OIL(INCLUDES 464,465,467,468-473)(INCLUDES OIL PUMP SPACER)

1262505
SPRING, Engine Oil Pressure, SPRING,OIL PRESSURE RELIEF VALVE
$1.33 $0.85

24506437
SCREEN, Engine Oil Pump, SCREEN,OIL PUMP(W/SUCTION PIPE)

11547525
BOLT, Engine Electrical, BOLT,ENGINE OIL MANIFOLD
- Require Quantity: 10
- Package Quantity: 1
$15.02 $7.96
1
Add To Cart

12582313
SEAL, Engine Front Cover & Crankshaft Seal, SEAL,CRANKSHAFT FRONT OIL
$24.24 $14.65
1
Add To Cart

12635958
SWITCH, Engine Oil Pressure/Temperature, SWITCH,ENGINE OIL PRESSURE INDICATOR(3/8 PIPE THREAD)(PART OF 440)(INCLUDES 729)
- Replaced By: 19436254
$51.28 $30.98
1
Add To Cart

12677837
SENSOR, Engine Oil Pressure/Temperature, SENSOR,ENGINE OIL PRESSURE
$103.06 $60.29
1
Add To Cart

12731179
FILTER, Engine Oil Filter, FILTER,OIL(PART OF 440)
$10.60 $5.62
12
Add To Cart

24504713
BOLT, Engine Oil Filter, BOLT,OIL FILTER ADAPTER(5/16-18 UNC-2AX1.50)(0.206)
- Require Quantity: 04
- Package Quantity: 10
$16.46 $10.46
10
Add To Cart

25013759
VALVE, Engine Oil Filter, VALVE,OIL FILTER BYPASS(PART OF 440)(OPENING PRESSURE 9-11 PSI NOMINAL)
$9.62 $5.10
1
Add To Cart

25519242
BOLT, Engine Oil Pump, BOLT,OIL PUMP COVER(1/4-20X.88)
- Require Quantity: 05
- Package Quantity: 1
$1.75 $1.12
1
Add To Cart

3522382
BOLT, Engine Oil Pump, BOLT,OIL PUMP SUCTION PIPE(HEX FLANGED HEAD,M6X1.0X28)
$2.63 $1.67
1
Add To Cart

3542258
NUT, Engine Oil Pump, NUT,OIL PUMP SUCTION PIPE(HEX FLANGED HEAD,M9X1)(1.430)
- Require Quantity: 06
- Package Quantity: 1
$6.58 $4.18
1
Add To Cart

3546580
PIPE, Engine Oil Pump, PIPE,OIL PUMP SUCTION
$50.04 $36.39
1
Add To Cart

11519173
BOLT, Engine Oil Filter, BOLT,HEX FLANGED HEAD,REDUCED BODY,M8X1.25X60,22THD,18 OUTSIDE DIAMETER,8.8,GMW3359(PART OF 440)
- Require Quantity: 03
- Package Quantity: 1

12552620
PLUG, Engine Oil Filter, PLUG,OIL FILTER BYPASS HOLE(PART OF 440)

12569215
ADAPTER, Engine Oil Filter, ADAPTER,OIL FILTER(W/BYPASS VALVE)(INCLUDES 409)

12575179
TUBE, Engine Oil Level, TUBE,OIL LEVEL INDICATOR(INCLUDES 432)

12581226
INDICATOR, Engine Oil Level, INDICATOR,OIL LEVEL(INCLUDES 434)

12586450
BAFFLE, Engine Oil Pan, BAFFLE,OIL PAN

12731175
FILTER, Engine Oil Filter, FILTER,OIL(DURAGUARD)
$8.76 $4.88

19418235
ADAPTER, Engine Oil Filter, ADAPTER,OIL FILTER(INCLUDES 441,442,445,446,449,457,728,729,900,901)(OFA WITH OIL COOLER (L37/LD8))

24505420
TUBE, Engine Oil Level, TUBE,OIL LEVEL INDICATOR(INCLUDES 419)

24505570
BOLT, Engine Oil Pump, BOLT,OIL PUMP SCREEN(HEX FLANGED HEAD 1/4-20 X .80")(W/.09 DOG POINT,.61 THREAD,.44 OUTSIDE DIAMETER,300M,7114M)
- Require Quantity: 02
- Package Quantity: 1
$9.14 $5.81

25530949
VALVE, Engine Oil Pressure, VALVE,OIL PRESSURE RELIEF(USE W/O TRANSVERSE HOLES/SLOT)

3530297
NUT, HEX FLANGED HEAD,M6X1,5.85THK,14.2 O.D.,10,ZINC ORGANIC(OIL LEVEL INDICATOR TUBE)
$7.26 $4.27
1
Add To Cart

Genuine GM Parts, the Right Choice

GMPartsGiant.com offers the wholesale prices for genuine 2005 Pontiac Bonneville parts. Parts like Engine Assembly-Oil Pump, Pan & Related Parts are shipped directly from authorized GM dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 6 Cyl 3.8L, 8 Cyl 4.6L. Model Code: GXP 4 DOOR, SE 4 DOOR, SLE 4 DOOR.
