Genuine Pontiac Exhaust Manifold
Engine Exhaust Manifold- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
145 Exhaust Manifolds found
Product Specifications- Other Name: Manifold, Exhaust ; Manifold, Engine Exhaust Manifold; Exhaust Manifold, Manifold
Pontiac Engine Exhaust Manifold
Part Number: 12643496$175.79 MSRP: $300.58You Save: $124.79 (42%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Manifold, Exhaust ; Manifold, Engine Exhaust Manifold; Exhaust Manifold
- Replaces: 12615133, 12630741
Pontiac Engine Exhaust Manifold
Part Number: 12603792$79.76 MSRP: $125.49You Save: $45.73 (37%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Manifold,Exhaust; Exhaust Manifold
Pontiac Engine Exhaust Manifold Assembly
Part Number: 96481526$126.85 MSRP: $180.14You Save: $53.29 (30%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Manifold Asm,Exhaust
Pontiac Engine Exhaust Manifold
Part Number: 12568405$203.34 MSRP: $303.21You Save: $99.87 (33%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Manifold, Exhaust ; Manifold, Engine Exhaust Manifold; Exhaust Manifold, Manifold
Pontiac Exhaust Manifold Assembly (W/ 3Way Catalytic Converter)
Part Number: 96476195$1221.80 MSRP: $1839.67You Save: $617.87 (34%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Manifold Asm,Exhaust (W/ 3Way Catalytic Converter); Exhaust Manifold
Pontiac Engine Exhaust Manifold Rear
Part Number: 12615497$324.83 MSRP: $660.74You Save: $335.91 (51%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Manifold, Exhaust Rear ; Manifold, Engine Exhaust Manifold; Exhaust Manifold, Manifold
- Position: Rear
Pontiac Exhaust Manifold Assembly Right (W/Heat Shield)
Part Number: 24500681$196.58 MSRP: $393.04You Save: $196.46 (50%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Manifold Assembly, Exhaust Right (W/Heat Shield); Exhaust Manifold, Manifold
- Position: Passenger Side
Pontiac MANIFOLD ASM,EXH (W/ 3WAY CTLTC CONV)"KIT"
Part Number: 19420129$1378.60 MSRP: $2066.66You Save: $688.06 (34%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Exhaust Manifold, Manifold
- Replaces: 12618546
Pontiac MANIFOLD ASM,EXH (W/ 3WAY CTLTC CONV)"KIT"
Part Number: 19420130$1745.02 MSRP: $2619.32You Save: $874.30 (34%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Exhaust Manifold, Manifold
- Replaces: 12586636, 12617358, 12618544
Pontiac Engine Exhaust Manifold
Part Number: 12571100$85.13 MSRP: $140.01You Save: $54.88 (40%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Manifold,Exhaust; Exhaust Manifold, Manifold
Pontiac Engine Exhaust Manifold
Part Number: 12580260$69.48 MSRP: $109.32You Save: $39.84 (37%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Manifold, Exhaust ; Manifold, Engine Exhaust Manifold; Exhaust Manifold
Pontiac Engine Exhaust Manifold
Part Number: 12587594$387.92 MSRP: $613.12You Save: $225.20 (37%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Manifold, Exhaust ; Manifold, Engine Exhaust Manifold; Exhaust Manifold
Pontiac Engine Exhaust Manifold Assembly
Part Number: 24576614$23.30 MSRP: $317.51You Save: $294.21 (93%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Manifold Assembly, Exhaust ; Manifold, Engine Exhaust Manifold; Exhaust Manifold, Manifold
Pontiac Engine Exhaust Manifold
Part Number: 12603753$218.06 MSRP: $340.05You Save: $121.99 (36%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Manifold, Exhaust Front ; Manifold, Engine Exhaust Manifold; Exhaust Manifold, Manifold
Pontiac Engine Exhaust Manifold
Part Number: 10182321$81.48 MSRP: $303.50You Save: $222.02 (74%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Manifold, Exhaust ; Manifold, Engine Exhaust Manifold; Exhaust Manifold, Manifold
Pontiac Exhaust Manifold Assembly (W/Crossover & Heat Shield) Light
Part Number: 24501743$66.86 MSRP: $615.29You Save: $548.43 (90%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Manifold Assembly, Exhaust (W/Crossover & Heat Shield) Light; Crossover Pipe, Exhaust Manifold, Manifold
Pontiac Engine Exhaust Manifold Assembly
Part Number: 12569054$183.58 MSRP: $290.15You Save: $106.57 (37%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Manifold Assembly, Exhaust ; Manifold, Engine Exhaust Manifold; Exhaust Manifold, Manifold
Product Specifications- Other Name: Manifold, Exhaust ; Manifold, Engine Exhaust Manifold; Exhaust Manifold
Product Specifications- Other Name: Manifold Assembly, Exhaust ; Manifold, Engine Exhaust Manifold; Exhaust Manifold, Manifold
| Page 1 of 8 |Next >1-20 of 145 Results
Pontiac Exhaust Manifold
If you're searching for OEM Pontiac Exhaust Manifolds, look no further. Our website boasts an extensive inventory of genuine Pontiac Exhaust Manifolds, all available at competitive prices online. Every part we offer comes with a manufacturer's warranty. In addition, we provide a straightforward return policy and rapid delivery services, making your shopping experience a breeze.
Pontiac Exhaust Manifold Parts Questions & Experts Answers
- Q: How to remove and reinstall the exhaust manifold and related components in four cylinder engine on Pontiac Fiero?A: Remove the air cleaner assembly and the preheat ducting between the exhaust manifold and the air cleaner. Take out the EFI throttle cable bracket bolt, the dipstick tube bracket bolt, and the ground strap bolt. Raise the vehicle and support it securely on jackstands, then remove the catalytic converter splash shield. Disconnect the exhaust pipe-to-exhaust manifold flange bolts, applying penetrating oil if they are corroded. If necessary, support the exhaust system with a piece of wire; if all mounting springs are intact, additional support may not be needed. Disconnect the oxygen sensor connector wire from its retaining clip and the electrical connector from the wire harness, noting that removal of the sensor from the manifold is only necessary if replacing the manifold. Label and disconnect the four spark plug wires, setting them aside. Loosen and remove the exhaust manifold retaining bolts and washers, starting with the end ones and then the middle ones, using penetrating oil if needed. Remove the exhaust manifold and gasket from the engine, ensuring the oil dipstick tube is pushed back into the block before reinstalling the manifold. Clean the gasket mating surfaces on the cylinder head and the exhaust manifold with a wire brush to remove all leftover gasket material and carbon deposits. Place a new exhaust manifold gasket on the cylinder head, position the manifold, and install the mounting bolts finger tight. The exhaust bolts are numbered from 1 to 7; tighten them gradually in the sequence 3-5-6-2-1-7-4 to the specified torque. Reattach the four spark plug wires and reconnect the oxygen sensor lead wire to the wire harness. Install a new exhaust manifold flange gasket between the exhaust manifold and the exhaust pipe, then tighten the exhaust manifold-to-exhaust pipe flange bolts. Reinstall the catalytic converter splash shield and tighten it securely, followed by the EFI throttle cable bracket. Finally, install the preheat ducting between the exhaust manifold and the air cleaner, then reinstall the air cleaner assembly. Start the engine and check for exhaust leaks between the exhaust manifold and cylinder head as well as between the exhaust manifold and the exhaust pipe.
- Q: How to remove and install an exhaust manifold in 2.3L four cylinder (Quad-4) engine on Pontiac Grand Prix?A: When replacing the exhausted manifold, you should follow these steps, The first thing that need to done is to unscrew the negative battery terminal; if there is an audio system with Theftlock system, make sure to turn it off. Then, disconnect the harness connector and oxygen sensor and then take off the manifold heat shields. Lift the car with jackstands safely and unbolt the exhaust pipe to manifold joint using a combination of penetrating oil, applying torque in left and right random cycle. Then unbolt the exhaust manifold brace and then loosen the nuts of the exhaust pipe flange from the manifold studs by pulling the pipe downwards slightly to ease off. Tighten the exhaust manifold mounting nuts an eighth of a turn clockwise each time from inside until they cannot be tightened any further, then remove the manifold bolts and remove the manifold from the head. Installation requires the mating surfaces of the manifold and cylinder head to be clean, use of gasket scraper to remove old gasket material and carbon deposits contour. A new gasket should be put in place, the manifold fasteners should be tightened by hand and then by a prescribed torque in the recommended sequence Finally other procedures will have to be reversed in the order of removal.
- Q: How should one properly remove and replace exhaust manifolds in V8 engine on Pontiac Firebird?A: If the car has air conditioning look at the routing of the hoses, and the position of the compressor, which in some cases can be removed without having to disconnect some of the exhaust manifolds; if not certain ask at the dealer or a local air conditioning specialist to depressurize the system and never disconnect the hoses that are pressurized. Start with the removal of the negative battery terminal next you the removal of the hot air pipe from the carbureted and TBI models right exhaust manifold to the air cleaner. Before removal, number the spark plug wires with tapes to facilitate reinstallation, removing the wires should be done by pulling on the rubber boot not the wire. The spark plug heat shields can be unbolted and the AIR hoses which are connected to the manifold check valve; the single metallic pipe and the AIR manifold can be together removed with the exhaust manifold. With out removing the hoses, remove the brackets holding the power steering pump and the air conditioning compressor from the left side manifold and place them aside. Remove the exhaust pipes from the manifold flanges and suspend the pipes on the frame with wire. Should there be bolt locking strips then you pry them up to the bolt heads to ease the process of unlocking. Loosen then take off the end bolts of the exhaust manifold then the center bolts; finally, pull the manifold and AIR injection tubes upward off the engine. Concerning the exhaust manifolds, when removing the old ones, carry along the carburetor hot air stove and the AIR injection tube system to the new manifolds. Remove the worn manifold and clean the mating surfaces on the cylinder heads and manifolds before fitting the new manifold, when tightening the bolts, start with the center bolts then the end bolts, if planning on spark plug access then fitting the left rear spark plug heat shield first will make access easier. Replace the other parts in the reverse order and put a new gasket or packing if required at the exhaust manifold to exhaust pipe flange joints and finally switch on the engine to look for exhaust leakages between the manifolds and the pipes.
